    Desktop Small Fiber Laser Marking Machine

    Ask Lasest Price
    Certification : CCC, Ce, ISO, SGS
    Price : US $3,800-7,000 / P
    • Product Details
    • Company Profile

    Desktop Small Fiber Laser Marking Machine

    Hot selling Table Design Fiber laser marking machine

    One year guarantee and life-time after sales service

    Desktop Small Fiber Laser Marking Machine

    1.Despriction of the Fiber Laser marking machine HBS-GQ-20B

    Fiber Laser Marking Machine is the latest generation of laser marking system, resulting from our own research using the world's most advanced laser technology.

    Adoption of fiber laser system for outputting laser, and then achieve marking functions by high-speed scanning galvanometer mirror system.

    The electro-optical conversion efficiency of fiber laser marking can reach 90% or above, it has higher beam quality in comparison to semiconductor laser marking machine.

    The machine is designed for long-time maintenance-free.


    2. Detailed Technical Information of fiber laser marking machine

    Laser Wavelength

    1060nm

    Beam Quality

    <1.5

    Laser Repetition

    ≤100KHz

    Standard Marking Area

    110mm x 110mm; Max:300mmx300mm

    Making Depth

    ≤1.5mm(Can be Adjustable)

    Marking Speed

    ≤12000mm/s

    Min. Line Width

    0.01mm

    Min. Character Size

    0.05mm

    Repetition Precision

    ±0.001mm

    Power Consumption

    ≤500W

    Cooling method

    Air cooled

    Power Supply

    220V/50Hz/10A


    l Optional Lens

    Lens Type

    HBS-65

    HBS-110

    HBS-175

    Focal Length

    100mm

    170mm

    250mm

    Marking Area

    65mm*65mm

    110mm*110mm

    175mm*175mm

    Note: Without special request, HBS will fix our standard lens Model: HBS-110


    3.Product Features of the fiber laser marking machine

    Extremely fast, with the high-speed galvanometer.

    Small volume, lightweight.

    No consumables, low power consumption, less than 500W.

    Completely air cooled, do not need water chiller, lower power consumption.

    Robust under harsh environment and temperature change can operate with batteries or supply from an automobile ci-garette lighter in case of power failure.

    Low product depreciation cost. Ability to meet customers' mass and stable production.

    4.Application of the fiber laser marking machine

    The machine is assembled with fiber laser from Germany or Britain or RAYCUS. The working time can reach 100,000 hours or above, competent in different work locations.

    Fiber laser marking machines are used in a wide variety of applications such as in the marking of gold, silver diamond and other jewelries, sanitary tools, food packaging, tobacco packaging, beer and beverage packaging, pharmaceutical packaging, medical equipments, watches & glassware, automotive parts, plastic & paper material, electronic hardware, gold bullion, and also in other areas such as aviation, aircraft manufacturing, projectile body and explosion proof materials.

    5. Marking samples of Laser marking HBS-GQ-20

    Desktop Small Fiber Laser Marking Machine
    6. Our Company
    Desktop Small Fiber Laser Marking Machine
    Desktop Small Fiber Laser Marking Machine
    Desktop Small Fiber Laser Marking Machine
